| University of Kentucky |
 |
| Gato del Sol V |
#3 |
 |
| L x W x H: |
4.90 m x 1.70 m x 1.00 m |
| Weight: |
300 kg |
| Array: |
1000 W Hybrid Si/GaAs |
| Pack: |
4.9 kWh INR (LiNiCoAlO2) |
| Motor: |
NGM SCM-150 |
| Wheels: |
3 Aluminum 16” |
| Chassis: |
Aluminum Space Frame |
|
| University of Florida |
|
| Torch |
#5 |
 |
| L x W x H: |
4.953 m x 1.778 m x 1.422 m |
| Weight: |
350 kg |
| Array: |
1120 W Suniva Silicon |
| Pack: |
5 kWh Lithium-Ion |
| Motor: |
Revolt DC Brushless |
| Wheels: |
3 Aluminum 19” |
| Chassis: |
Aluminum Space Frame |
|
| UC Berkeley |
|
| Zephyr |
#6 |
 |
| L x W x H: |
4.92 m x 1.77 m x 1.07 m |
| Weight: |
195 kg |
| Array: |
1200 W SunPower Silicon |
| Pack: |
5.0 kWh Lithium-Ion |
| Motor: |
Dual 1kW Mitsuba M 1096-II |
| Wheels: |
4 Carbon Fiber 16” |
| Chassis: |
Aluminum Space Frame |
|
| UT Austin |
|
| TexSun |
#8 |
 |
| L x W x H: |
5.0 m x 1.8 m x 1.4 m |
| Weight: |
243 kg |
| Array: |
1346 W SunPower Silicon |
| Pack: |
4.3 kWh Lithium Ion Phosphate |
| Motor: |
Permanent Magnet NGM |
| Wheels: |
3 NGM 14″ |
| Chassis: |
Aluminum Space Frame |
|
| Northwestern University |
|
| SC6 |
#11 |
 |
| L x W x H: |
4.75 m x 1.54 m x 0.91 m |
| Weight: |
250 kg |
| Array: |
1682 W SunPower Silicon |
| Pack: |
3.5 kWh Lithium-Ion |
| Motor: |
NGM SCM 150 |
| Wheels: |
3 Carbon Fiber 14” |
| Chassis: |
Carbon Fiber Monocoque |
|
| Michigan State University |
|
| Leonidas |
#13 |
 |
| L x W x H: |
4.8 m x 1.5 m x 1.7 m |
| Weight: |
220 kg |
| Array: |
1337 W SunPower Silicon |
| Pack: |
5.3 kWh Lithium Ion |
| Motor: |
NGM SCM 150 |
| Wheels: |
3 Carbon Fiber |
| Chassis: |
Chromoly Space Frame |
|
| Illinois State University |
|
| Mercury 5s |
#17 |
 |
| L x W x H: |
4.52 m x 1.70 m x 1.10 m |
| Weight: |
237 kg |
| Array: |
1100 W SunPower Silicon |
| Pack: |
5.0 kWh Lithium-Ion |
| Motor: |
Mitsuba 3 Phase AC |
| Wheels: |
4 Aluminum 14” |
| Chassis: |
Carbon Fiber |
|
| University of British Columbia |
 |
| Raven |
#26 |
 |
| L x W x H: |
4.80 m x 1.80 m x 1.00 m |
| Weight: |
273 kg |
| Array: |
1300 W SunPower Silicon |
| Pack: |
3.2 kWh Lithium-Ion |
| Motor: |
PERM Brushed DC |
| Wheels: |
3 Aprilia E DOT-D 16″ |
| Chassis: |
Chromoly Space Frame |
|
| Principia |
|
| Ra X |
#32 |
 |
| L x W x H: |
3.38 m x 1.6 m x 1.07 m |
| Weight: |
150 kg |
| Array: |
1000 W SunPower Silicon |
| Pack: |
5.0 kWh Lithium Polymer |
| Motor: |
Mitsuba Hub Motor |
| Wheels: |
4 Carbon Fiber 16″ |
| Chassis: |
Chromoly Space Frame |
|
| Missouri S&T |
|
| Solar Miner |
#42 |
 |
| L x W x H: |
4.64 m x 1.62 m x 1.04 m |
| Weight: |
158 kg |
| Array: |
1310 W Sunpower Silicon |
| Pack: |
5.4 kWh Lithium-Ion |
| Motor: |
Custom Axial Flux Hub Motor |
| Wheels: |
3 Custom Billet 16″ |
| Chassis: |
Carbon Fiber Monocoque |
|
| Georgia Institute of Technology |
|
| SR-2 |
#49 |
 |
| L x W x H: |
4.5 m x 1.8 m x 1.6 m |
| Weight: |
250 kg |
| Array: |
1120 W SBM Solar Mono-Si |
| Pack: |
4.0 kWh LiFePO4 |
| Motor: |
Marand Permanent Magnet |
| Wheels: |
4 Carbon Fiber 22″ |
| Chassis: |
Aluminum Space Frame |
|
| Polytechnique Montreal |
|
| Esteban 8 |
#55 |
 |
| L x W x H: |
4.72 m x 1.74 m x 1.06 m |
| Weight: |
212 kg |
| Array: |
1300 W SunPower Silicon |
| Pack: |
5.0 kWh Lithium-Ion |
| Motor: |
2 Mitsuba Wheel Motors |
| Wheels: |
4 Energizer Solar 21” |
| Chassis: |
Carbon Fiber Monocoque |
|
| Southern Illinois Univ Edwardsville |
|
| NOVA |
#57 |
 |
| L x W x H: |
4.52 m x 1.70 m x 1.12 m |
| Weight: |
215 kg |
| Array: |
1000 W SunPower Silicon |
| Pack: |
5.0 kWh Lithium-Ion |
| Motor: |
7.5kW NGM SCM150 |
| Wheels: |
3 Aluminum 14” |
| Chassis: |
Chromoly Space Frame |
|
| École de Technologie Supérieure |
|
| Éclipse 9 |
#92 |
 |
| L x W x H: |
4.50 m x 1.79 m x 1.25 m |
| Weight: |
220 kg |
| Array: |
1400 W Sunpower Silicon |
| Pack: |
5.0 kWh Lithium-Ion |
| Motor: |
2 Csiro/Marand w/ Custom Housing |
| Wheels: |
4 Aluminum 16” |
| Chassis: |
Titanium Space Frame |
|
| Western Ontario University |
|
| SunStang |
#96 |
 |
| L x W x H: |
5.0 m x 1.7 m x 1.2 m |
| Weight: |
275 kg |
| Array: |
1100 W Mootech Industries Inc. Silicon |
| Pack: |
3.5 kWh Lithium Polymer |
| Motor: |
1 NGM |
| Wheels: |
3 Aluminum 16” |
| Chassis: |
Aluminium Space Frame |
|
| Western Michigan University |
|
| Farasi |
#786 |
 |
| L x W x H: |
4.47 m x 1.96 m x 1.19 m |
| Weight: |
300 kg |
| Array: |
1340 W SunPower Silicon |
| Pack: |
5.1 kWh Lithium-Ion |
| Motor: |
2 CSIRO |
| Wheels: |
4 Aluminum 16” |
| Chassis: |
Carbon Fiber Monocoque |
|
| University of Puerto Rico – Mayaguez |
 |
| El Pitirre |
#787 |
 |
| L x W x H: |
4.48 m x 1.80 m x 1.06 m |
| Weight: |
272 kg |
| Array: |
850 W Sunpower Silicon |
| Pack: |
5.1 kWh Lithium-Ion |
| Motor: |
Nugen Mobility Inc. BLDC Triphasic |
| Wheels: |
3 Ecopia ep 80 14” |
| Chassis: |
Aluminum Space Frame |
|
| Appalachian State |
|
| Apperion |
#828 |
 |
| L x W x H: |
4.97 m x 1.72 m x 1.21 m |
| Weight: |
190 kg |
| Array: |
1200 W SunPower Monocrystalline |
| Pack: |
4.2 kWh Lithium-Ion |
| Motor: |
Mitsuba M2096-DIII |
| Wheels: |
3 Aluminum 14” |
| Chassis: |
Aluminum Space Frame |
|
